Arcade games in the browser: getting MAME to finally run

I used to see games like Golden Axe and Gyruss in the arcade, and I wanted them on a web page.

There is a 23.6 MB JavaScript file sitting in an old folder on my machine. It is a complete multi-arcade emulator, cross-compiled from C++ to WebAssembly. It never successfully booted a single game in a browser.

This is the story of why that file failed, why the problem it ran into is the same problem every browser-emulation project hits, and how — a year later — a little build tool called jamma finally got sixty-one arcade games running at a steady 60 fps on a static web page, on the current version of MAME.

The graveyard of browser MAME

Putting MAME in a browser is an old idea with a famous success story: in November 2014, the Internet Archive launched the Internet Arcade — "over 900 arcade machines", per Jason Scott's launch post, covering "most every major machine released between 1976 and 1988" — powered by JSMESS, a JavaScript port of MAME/MESS (blog.archive.org). That collection is still up and now holds 2,663 items.

What's remarkable is how little the underlying recipe has changed since. MAME's own build documentation describes an Emscripten target — compile with SOURCES=<driver files>, get a .js + .wasm, wrap it in an HTML loader — and then points you at The Emularity, the same loader the Internet Arcade used in 2014 (docs.mamedev.org/initialsetup/compilingmame.html). No official modern loader has replaced it.

The mainstream alternative sidesteps MAME entirely. EmulatorJS — a web frontend for RetroArch, about 4,300 stars on GitHub — ships arcade games through the FBNeo core by default, or MAME 2003 — which is MAME 0.78, from December 2003 (emulatorjs.org/docs/systems/arcade). That's not a slight: old MAME is faster, smaller, and its frozen ROM sets are stable. But it's twenty-three years of emulation research on the shelf.

And the hobbyist projects that did try current-ish MAME in a browser tend to stall. The best documented one I found, ybootin/mamejs (MAME 0.178, Docker-based build, 19 stars), hasn't had a commit since June 2017. My own attempt was built on it.

Attempt one: the 23.6 MB file that wouldn't boot

In late 2025 I tried. I compiled mamejs myself — my notes from that week are just the sentence "i cant get the roms to work, so i'm going to try to compile mamejs myself" and a Docker command.

The post-mortem found two independent failures stacked on top of each other:

• The demo page hardcoded absolute local ROM paths, loaded with XMLHttpRequest — which 404s over HTTP and is blocked outright on file://.
• The ROM zips were packs from a MAME 0.198-era set, but the core was built from MAME 0.178. MAME ROM sets are only valid for the MAME version they were built for — more on that below, because it turned out to be the real story.

Both were fixable. But stacked together, each fix revealed the next failure, and the project went back on the shelf.

Attempt two: verify first, build second

The redo, in 2026, inverted the order of operations. jamma (named for the JAMMA edge connector that standardized arcade cabinet wiring) is a build tool plus a browser loader, and its first rule is: don't trust a single ROM zip until you've checked it against the exact emulator binary you're going to ship.

MAME can dump the full requirements of any driver — every file, its expected size and CRC — and it tells you how it matches files inside an archive: first by name and CRC together, then by CRC alone anywhere in the zip, then by filename alone (docs.mamedev.org/usingmame/assetsearch.html). jamma's verify script follows the same idea in simplified form, against MAME 0.289's own manifest: a ROM counts as present if its checksum appears anywhere in the set's zip (or in its parent, BIOS or device zips), or if a loose file in the set's folder has the right name and checksum. So "verified" means this zip loads on this build, not "the filenames look right".

The verdict on my ROM folder: of 71 sets, 60 passed, 1 passed with a warning (a file with a wrong checksum — MAME loads it anyway), and 10 were dead — gng, raiden, cabal, commando, bloodbro and friends, all missing required ROMs their version of the set simply never contained.

Your ROM zip is lying to you

Why would a zip of, say, Ghosts 'n Goblins just not work on a modern MAME? Because a ROM set is not a copy of a game — it's a snapshot of what the preservation community knows about a board at a point in time.

MAME's documentation is unusually honest about this (docs.mamedev.org/usingmame/aboutromsets.html): early dumps missed entire chips (color PROMs); bad dumps got re-dumped later; games long labeled as legit turned out to be bootlegs, or the other way around; and occasional "miracle finds" — like the protection-chip dumps that unlock a machine's hidden behavior — get added.

My favorite concrete case in the folder: Golden Axe. On MAME 0.289 the set wants a file called 315-5298.b9 — a dump of a programmable logic device (a PLS153) off the Sega System 16B board. Zip packs from years past never contained it, because it hadn't been dumped yet. The game ran without it on old MAME; modern MAME, which reproduces the hardware, knows what it's missing.

This is exactly the trade the easy web-arcade stacks make: MAME 2003's baseline is 4,705 sets frozen in December 2003 — stable and fast, and forever blind to thirty more years of chip dumps, re-dumps and corrections.

None of this is pedantry. MAME's stated purpose is preservation — "to document the hardware and reproduce the behavior of the hardware as faithfully as possible" — and speed is explicitly not the goal (docs.mamedev.org/initialsetup/mameintro.html). Ten dead zips is what thirty years of that mission looks like from the outside.

Compiling the core

With a verified set list, the build itself follows MAME's official Emscripten recipe: emsdk 6.0.12 (MAME 0.289 builds against SDL3, which needs a recent Emscripten), SOURCES= with the driver files, out comes .js + .wasm. jamma pins MAME 0.289 — the current release — and builds per-collection cores rather than one monolith, because as the docs put it, a full MAME compile is too large to load into a browser at once. The arcade core compiles 47 driver files into 61 playable sets; smaller cores cover Sega System 16 and the 1942/1943 Capcom games.

The docs also warn — accurately — that the dependency discovery "is not automated": sometimes you must manually add source files, and "unresolved symbol" warnings at link time are expected for OpenGL-related functions. jamma keeps an extraSources list for exactly that case, but this core didn't need it. The one thing that did break the build was a compiler warning treated as an error, in MAME's CPU recompiler (drcbec.cpp), about a floating-point pragma clang ignores when targeting WebAssembly; NOWERROR=1 lets the build carry on. (And yes — you need a real web server; file:// will never work, which is failure #1 from attempt one all over again.)

Getting Golden Axe to boot

The first boot was a black canvas and a bare CppException in the console. MAME had found the game, then stopped: the 315-5298.b9 PLD dump from the last section was missing, and a missing required file is fatal. A wrong checksum, though, is only a warning. MAME doesn't use that chip to run Golden Axe, so a 235-byte placeholder file with the right name got past the check, with a "WRONG CHECKSUMS" note in the log.

The second boot crashed on glShadeModel. MAME's default OpenGL renderer calls desktop GL functions that WebGL doesn't have; switching to its bgfx renderer (-video bgfx) fixed it, and Golden Axe's FBI warning screen appeared. One more surprise: MAME's own JavaScript bindings for mute, the FPS display and reset are created before the WebAssembly finishes loading, so most of them came out undefined. jamma rebinds them once the runtime is ready.

60 fps without the busy-wait

Once games booted, Gyruss ran badly, hovering around 49.7 fps. The culprit was MAME's own throttle: to hit its target frame rate it busy-waits, burning roughly a third of each 16.7 ms frame doing nothing (Golden Axe: 15.8 ms per frame with it on).

The fix sounds wrong and works beautifully: run MAME with throttling off (-nothrottle) and pace it from JavaScript instead. In the browser, each pass of MAME's main loop emulates exactly 1/60 s and runs on requestAnimationFrame. jamma hooks Emscripten's MainLoop.preMainLoop and skips passes that arrive early, so a 120 Hz display doesn't run the game twice as fast. Gyruss: a steady 60 fps, 9.2 ms per frame. Golden Axe: 10.9 ms. The trade-off found in testing: MAME's -autoframeskip only works when its throttle is on, so that's off the table — the JavaScript pacer is the frame limiter now.

Shipping 44 MB

One arcade.wasm: 44,355,473 bytes. Too heavy for a casual click. Brotli-compressed per-build it drops to 6.2 MB (8.3 MB gzip for plain-HTTP LAN serving), served with Content-Encoding and an ETag → 304 dance. That's the difference between "I'll download it later" and "oh, it just loaded".

The honest benchmark epilogue

The obvious next question: compile-time flags. WASM SIMD (-msimd128)? Link-time -O3 (jamma's README notes MAME caps the emcc link at -O2)? Both built; 5 games × 3 cores × 2 runs measured. The result: no net gain. Gyruss got 11% (and with -O3, 21%) faster; Golden Axe got slower by 18% and 10%; everything else shuffled within noise; the average moved 0% / −1%. Both experiments went in the bin. On a browser port of an accuracy-first emulator, the algorithmic hot spots don't care about your flags — which, given MAME's stated priorities, feels about right.

Sixty-one games

The example page now boots any of the 61 verified sets from a dropdown, with gamepads, fullscreen, and the MAME internal menu a keypress away (the loader also exposes save states for apps built on it). The controller's Back button drops a coin and Start starts the game, exactly like the cabinet wanted.

And the games themselves are a decent argument for doing this on current MAME. Of the six I tested most, three share an author: Yoshiki Okamoto designed Konami's Gyruss (March 1983 — the tube shooter set to a Bach Toccata and Fugue, an early arcade game with stereo sound), was fired over pay disputes, joined Capcom, designed 1942, and worked on Forgotten Worlds (May 1988 — the first game on the CP System, CPS-1) before producing Street Fighter II. Around them: Namco's Xevious (January 1983 in Japan; Atari famously advertised it in North America as "the Atari game you can't play at home" — one of the first games with a boss fight), Sega's Golden Axe (1989, System 16B), and Video System's Aero Fighters (1992, Sonic Wings in Japan, whose designer Shin Nakamura left to found Psikyo).

I used to see these games in the arcade. Now they boot from a dropdown on a web page, on the current MAME, at full speed.

---

Sources: the links throughout this post. jamma's README documents the exact flags and numbers; ROM status is reproducible with mame -listxml and any zip CRC tool. MAME is GPL-2.0-or-later; it ships no game ROMs — a handful are freely redistributable via mamedev.org/roms, and the Internet Archive removes titles on rightsholder request.
